S7110 Low Profile Servo Winch: 1/10 Rock Crawlers

Item No. SPMSS7110
Brand Logo
4.8 out of 5 Customer Rating

S7110 Low Profile Servo Winch: 1/10 Rock Crawlers

Item No. SPMSS7110
$159.99
RC Club points earned on this item shown at checkout.
Only manufacturer discounts can be applied to this product. Tower Hobbies coupon codes not applicable
In Stock
Selected Store

Product Details

icon-box
In The Box
  • (1) S7110 High Voltage Servo Winch
  • (1) Scale recovery hook
  • (1) Aluminum spool
  • (1) 7’ Fiber line
S7110 Low Profile Servo Winch: 1/10 Rock Crawlers

Features

  • Design for 1/10th Scalers and Crawlers
  • 6V to 8.4V Operating Voltage
  • Durable and long-lasting brushless motor
  • High Torque (130oz-in @ 6V, 160oz-in @ 7.4V, and 180 oz-in @ 8.4V)
  • All Aluminum servo case for heat dissipation
  • 7' feet of line with scale recovery hook included
  • Built-in Integrated brushless controller for easy set up and installation
  • Precise metal internal gears
  • Waterproof
  • 25 teeth output shaft
  • Includes everything needed to start winching

Overview

The Spektrum servo winch offers incredible performance for 1/10th scaler and crawlers. High voltage capable, the servo winch can produce 160 oz of torque at 155RPM at 7.4V input. It's low-wear, metal gear drive train is powered b a brushless motor and bearing supported for smooth operation. Like all Spektrum servos, the S7110 Servo Winch delivers reliability, consistency, and performance that is second to none.

Product Specifications

Application 1/10 Rock Crawlers- Winch
Bearing Ball Bearing
Bushing Or Bearing Bearing
Connector Type Universal
Connector Wire Length 7.48" (190 mm)
Current Draw Idle 2mA
Current Draw Stall 1.6A @ 6.0V, 1.8A @ 7.4V, 2A @ 8.4V
Gear Type Metal
Input Voltage 6.0V ~ 8.4V
Maximum Servo Speed 123RPM @ 6.0V, 155RPM @ 7.4V
Maximum Servo Torque 130oz/in @ 6.0V, 160oz/in @ 7.4V, 180oz/in @ 8.4V
Product Height 0.99" (25 mm)
Product Length 1.59" (40 mm)
Product Weight 2oz (57g)
Product Width 0.8" (20 mm)
Programmable No
Prop 65 Prop 65 Warning Icon  California Residents Prop 65 WARNINGS.
Rotation Range 360 Degree Continuous
Servo Operating Voltage 6.0 - 8.4V (HV)
Servo Size Category Low Profile
Servo Type Digital
Spline Count 25 - Tooth
Wire Gauge 22 AWG
