Avian 6362-200Kv Outrunner Brushless Motor

Item No. SPMXAM4796
Backorder
Brand Logo
4.9 out of 5 Customer Rating

Avian 6362-200Kv Outrunner Brushless Motor

Item No. SPMXAM4796
$179.99
RC Club points earned on this item shown at checkout.
Select Options
Avian 120 Amp Brushless Smart ESC 6S - 12S
SPMXAM4796 SPMXAE1120HV
Avian 120 Amp Brushless Smart ESC 6S - 12S
In Stock
$219.99
0 Item Selected Items Selected
Electric Propeller, 16 x 8E
SPMXAM4796 APC16080E
Electric Propeller, 16 x 8E
In Stock
$9.54
Electric Propeller, 19 x 10E
SPMXAM4796 APC19010E
Electric Propeller, 19 x 10E
In Stock
$15.59
0 Item Selected Items Selected
Next Shipment May 2024
Selected Store

Product Details

Take to the Skies with Spektrum Avian Brushless Motors for Fixed-wing Models

The combination of superior performance, high reliability and user-friendly features makes the Spektrum Avian Brushless Motors an excellent choice for your next aircraft project. Plus, the wide selection means there's Avian Brushless motor that's ideal for whatever the application, including brushed-to-brushless upgrades as well as combustion-to-electric conversions. Equip your airplane with an Avian motor to compliment your Smart Technology equipped models!

Key Benefits

  • Rapid Acceleration and Extreme Torque: Expertly engineered to deliver fast, smooth and precise acceleration and power.
  • Reliable and Virtually Maintenance Free: Equipped with double-shielded sealed bearings, precision balanced motor bell and gold-plated bullet connectors.
  • Excellent Cooling: Engineered to help airflow move through the motor for efficient cooling during and after flight.

Features

  • Lightweight design
  • Excellent power and efficiency on 12S power when matched with a 18x10 size propeller
  • Powerful and durable Rare-Earth Neodymium magnets
  • 14-pole stator for smooth and precise propulsion
  • Includes all required hardware: preinstalled gold-plated bullet connectors, aluminum motor mount, prop adapter and female ESC connectors
  • Perfect match for the Spektrum Smart Avian 120 amp HV ESC
  • Perfect electric conversion upgrade for 30cc size gas combustion power systems running 12S LiPo power

Important Specs

  • Recommended Voltage Range – 33.3 - 44.4V / 9-12S LiPo
  • Recommended Propeller Range – 16x8 to 19x10 Electric Propeller
  • Recommended Model Flying weight – 3D 5445g (12 lbs) - Sport 9070g (20 lbs)
  • Max Wattage – 1900w
  • Max Current – Max Burst Amps (100A) Max Continuous Amps (60A)

Product Specifications

Integrated ESC No
Motor Design Outrunner
Bearing Yes
Forward Yes
Shaft Length 1.41733" (36 mm)
Outer Diameter 2.5" (64 mm)
Connector Type 4mm Bullet
Motor Class Large
Motor Size 6362-200Kv Brushless Outrunner
Product Length 2.4" (61 mm)
Kv Rating 0-250Kv
Motor Output Lead 4
Recommended Speed Control Avian 120 Amp Brushless Smart ESC
RPM/Volt (Kv) 200Kv
Sensor Type Sensorless
Application Airplane
Number of Poles 14
Product Weight 22.4 oz (635 g)
Recommended Prop Range 16x8 to 19x10 Electric Propeller
Shaft Diameter 0.375" (10 mm)
Constant Wattage 2000-2499W
Maximum Burst Current 77A
Maximum Continuous Current 48A
Motor Type Brushless
Speed Control Sold Separately
Input Voltage 33.3 - 44.4V / 9-12S LiPo
