Powerstage Bundle - Stage 4: 4S (2 x 2S) LiPo: EC5

Item No. DYN1530
Discontinued
Brand Logo
4.7 out of 5 Customer Rating

Powerstage Bundle - Stage 4: 4S (2 x 2S) LiPo: EC5

Item No. DYN1530
This item is no longer available. Updated or related products shown below:
Smart Powerstage Bundle 4S
Smart Powerstage Bundle 4S
SPMXPS4
View Alternate Product Details

Product Details

Key Features

  • Included Passport Ultra P2 100W AC Plus 2-Port AC/DC Multi-Charger:
    • Powerful 100W AC/DC Multi-Charger
    • Two channels charge two different kinds of batteries simultaneously
    • Charges LiPo, LiHV, LiFe NiMH/NiCd, and Pb batteries
    • Charges 1-6 cell LiPo/ LiHV/LiFe, 1-15 cell NiMh/NiCd, and 2-20V Pb
    • Dynamite Dashboard-Smart phone control and monitor via Bluetooth
    • High visibility, simplified LCD interface
    • Built-in balancing ports
    • Integrated voice functionality
    • 5-year limited warranty
  • Included (2) Reaction HD 7.4V 5000mAh 50C 2S LiPo, Hardcase: EC5 (DYNB3810EC)
    • 1-Year limited warranty
    • Pre-wired with an EC5™ connector and JST-XH balance connector
    • Value-priced without sacrificing quality or performance
    • Hard case design
    • Designed to fit 1/10-, 1/8-, and 1/6-scale platforms
    • Backed by Horizon Hobby

Overview

The new Powerstage 4S & 6S bundles are perfect for larger scale vehicles. Designed to work specifically with Losi and ARRMA 4S & 6S vehicles, Dynamite’s new Powerstage bundles offer convenience and performance in a 1-box solution. Additionally, and for select dual-battery Pro Boat models, the 4S and 6S Powerstage options offer a solid solution that has been designed to handle extreme amperage requirements. Each bundle includes the popular DYNC3016 Passport Ultra P2 AC Plus 2-Port AC/DC Multi-Charger to make charging a breeze, (2) 2S or 3S batteries, (2) banana to EC5 connectors and (2) EC5 to XT90 connectors for use in compatible ARRMA vehicles.

Product Specifications

Specs

Output 200W max
Output Connector Banana plug to EC3
Number of Cells 2
PC Connectivity Yes - USB, external adapter required
Over Current Protection Yes
Normal/Standard Charge Current 5.0A
Voltage Meter Yes - on main LCD display
Watt Hours 37.0
Wire Gauge 12 AWG
Product Weight 1.4 lbs (668g)
Peak Detection Yes
Safety Timer Yes
Reverse Polarity Protection Yes
Selectable Charge Rate Yes
Short Circuit Protection Yes
Thermal Protection Yes
Software Updates Yes
Low Input Voltage Protection Yes
Input Connector AC cord detachable, North American plug
Input Voltage 100 - 240V AC, 11 - 18V DC
Integrated Balancing Yes - Internal Balancer & External Adapter
Hard Case Yes
Connector Type EC5
Balance Lead Length 2.16" (55mm)
Battery Balance Connector JST_XH
Battery Capacity 5000-5999mAh
Battery Temperature Monitoring Yes - Temperature Sensor not included
Battery Voltage 7.4V
Application Surface
Cooling Method Cooling fan
Discharge No/Yes
Discharge Lead Length 3.94" (100mm)
Display LCD
Capacity 5000mAh
Cell Configuration 2S1P
Charge Protection Circuitry No
Amp Meter Yes - on main LCD display
