HSB-9370TH Brushless Titanium Gear Servo

Item No. HRC39373S
HSB-9370TH Brushless Titanium Gear Servo
HSB-9370TH Brushless Titanium Gear Servo
HSB-9370TH Brushless Titanium Gear Servo
HSB-9370TH Brushless Titanium Gear Servo
Brand Logo
5 out of 5 Customer Rating

HSB-9370TH Brushless Titanium Gear Servo

Item No. HRC39373S
$189.99
RC Club points earned on this item shown at checkout.
In Stock
Selected Store
The link to HSB-9370TH Brushless Titanium Gear Servo has been copied

Product Details

With ultra-efficient brushless motors, titanium gear trains, low current consumption and constant output power, the HSB-93XX series of servos is the perfect match for the most discriminating pilots and racers.
Key Features
  • Speed: @4.8V .12sec/60' / @7.4V .10sec/60'
  • Torque: @7.4V 347oz/in
  • Programmable 12-Bit PWM Digital Amplifier
  • Custom Long Life Brushless Motor
  • 1M Cycle Long Life Potentiometer
  • Constant Output Torque
  • Wide Operating Voltage (5 ~ 9 Volts DC)
  • Dual Ball Bearing Supported Output Shaft
  • Dust Resistant and Splash Proof Case
  • 25-Tooth Output Spline
  • Hybrid Nylon Reinforced Plastic and Aluminum Case
  • Low Power Consumption
icon-box
In The Box
  • (1) HSB-9370TH Brushless Titanium Gear Servo
HSB-9370TH Brushless Titanium Gear Servo
Quick Links
icon-pdf-download Manuals & Support

Product Specifications

Bearing Dual Ball Bearing
Bushing Or Bearing Bearing
Gear Type Metal
Wire Gauge 20 AWG
Current Draw Stall 2,100 mA
Gear Material Titanium
Motor Type Brushless
Servo Operating Voltage 6.0 - 7.4V (HV)
Programmable Yes
Servo Size Category Standard
Maximum Servo Torque 347oz/in @ 6.0V ~ 7.4V
Connector Type Universal
Maximum Servo Speed 0.12 sec/60 deg @ 6.0V, 0.10 sec/60 deg @ 7.4V
Product Length 1.57" (40 mm)
Current Draw Idle 27 mA
Product Width 0.79" (20 mm)
Deadband 1µs
Input Voltage 6.0V ~ 7.4V
Product Height 1.5" (38 mm)
Servo Type Digital
Application High Performance Aircraft, Cars, Boats
Product Weight 2.4oz (68.0g)
Spline Count 25 - Tooth
Water-Resistant No
