HS-82MG Micro Analog Metal Gear Servo

Item No. HRC32082S
HS-82MG Micro Analog Metal Gear Servo
HS-82MG Micro Analog Metal Gear Servo
HS-82MG Micro Analog Metal Gear Servo
HS-82MG Micro Analog Metal Gear Servo
Brand Logo
5 out of 5 Customer Rating

HS-82MG Micro Analog Metal Gear Servo

Item No. HRC32082S
$23.99
RC Club points earned on this item shown at checkout.
In Stock
Selected Store
The link to HS-82MG Micro Analog Metal Gear Servo has been copied

Product Details

Hitec took one of their top selling servos and made it even better. Based on the ultra popular HS-81MG the HS-82MG gets a new stronger motor and updated electronics for more precise centering. The HS-82MG is perfect for smaller aircraft and helicopters where a durable geartrain is required.
Key Features
  • Speed: @4.8V .12sec/60' / @6.0V .10sec/60'
  • Torque: @4.8V 38.88oz/in / @6.0V 47.22oz/in
  • Top Selling Metal Gear Micro Servo
  • Strong Three-Pole Ferrite Motor
  • Rugged Metal Gears
icon-box
In The Box
  • (1) HS-82MG Micro Analog Metal Gear Servo
HS-82MG Micro Analog Metal Gear Servo
Quick Links
icon-pdf-download Manuals & Support

Product Specifications

Deadband 5µs
Input Voltage 4.8V ~ 6.0V
Product Height 1.16" (29 mm)
Servo Type Analog
Connector Type Universal
Maximum Servo Speed 0.12 sec/60 deg @ 4.8V, 0.10 sec/60 deg @ 6.0V
Current Draw Idle 10mA
Product Width 0.47" (12 mm)
Programmable No
Servo Size Category Micro
Application Small Electric Aircraft and Helicopters
Product Weight 0.66oz (19.0g)
Spline Count 24 - Tooth
Water-Resistant No
Current Draw Stall 1,800 mA
Motor Type Brushed
Servo Operating Voltage 4.8 - 6.0V
Maximum Servo Torque 39oz/in @ 4.8V, 47oz.in @ 6.0V
Product Length 1.17" (30 mm)
Bearing None
Bushing Or Bearing Bushing
Gear Type Metal
Wire Gauge 28 AWG
