HS-5087MH Micro Digital HV Metal Gear Servo

Item No. HRC35087S
Brand Logo
3.8 out of 5 Customer Rating

HS-5087MH Micro Digital HV Metal Gear Servo

Item No. HRC35087S
$42.99
RC Club points earned on this item shown at checkout.
In Stock
Selected Store

Product Details

The HS-5087MH digital, metal gear micro servo is the high voltage version of our ever popular HS-5085MG. Built with a 3-pole ferrite motor and heavy-duty metal gears, this servo will bring maximum performance to your hobby and deliver extra power with a 2-cell 7.4V LiPo battery. Whether you are a beginner or an expert in the RC field, our HS-5087MH will provide the strength and capability you need and want in a micro servo. Drivers will find it the perfect steering servo for their 1/16th scale vehicles. Pilots with .15 to .40-size glow and electric aircraft will relish in its power and reliability. Its precision and performance also make it perfect for 500-size helicopters.
Key Features
  • Speed: @4.8V .17sec/60' / @6.0V .13sec/60'
  • Torque: @4.8V 50oz/in / @6.0V 60oz/in
  • Rugged Metal Gears
  • Ball Bearing-Supported Output Shaft
  • Standard Programmable Digital Circuit for More Holding Power
  • Standard Servo Performance in a Micro Package
icon-box
In The Box
  • (1) HS-5087MH Micro Digital HV Metal Gear Servo
HS-5087MH Micro Digital HV Metal Gear Servo

Product Specifications

Maximum Servo Torque 50oz/in @ 6.0V, 60oz/in @ 7.4V
Bearing Top Ball Bearing
Bushing Or Bearing Bearing
Gear Type Metal
Wire Gauge 28 AWG
Deadband 2┬Ás
Input Voltage 6.0V ~ 7.4V
Product Height 1.18" (30 mm)
Servo Type Digital
Programmable Yes
Servo Size Category Micro
Current Draw Idle 3 mA
Product Width 0.51" (13 mm)
Current Draw Stall 1,750 mA
Motor Type Brushed
Servo Operating Voltage 6.0 - 7.4V (HV)
Water-Resistant No
Application 50oz park flyers, 42-50oz sport planes, 2M/DLG sailplanes, 1:16 scale on-road, buggies & SC trucks, 1:16 scale power boats
Product Weight 0.77oz (21.9g)
Spline Count 24 Teeth
Connector Type Universal
Maximum Servo Speed 0.17 sec/60 deg @ 6.0V, 0.13 sec/60 deg @ 7.4V
Product Length 1.14" (29 mm)
