DB961WP Servo 20mm Brushless Steel Gear Waterproof

Item No. HRC36961S
Brand Logo
5 out of 5 Customer Rating

DB961WP Servo 20mm Brushless Steel Gear Waterproof

Item No. HRC36961S
$179.99
RC Club points earned on this item shown at checkout.
In Stock
Selected Store

Product Details

Now more than ever, today’s competition quality off-road vehicles and giant scale aircraft demand uncompromised quality and performance in the never-ending race for gold.
Key Features
  • Machined Aluminum
  • Dual Oversized Bearings
  • Hardened Steel Gear Train
  • 3 Hardened Steel Pins
icon-box
In The Box
  • (1) DB961WP Servo
  • (1) Set Of Servo Horns
DB961WP Servo 20mm Brushless Steel Gear Waterproof

Introduction

The new Ultra-Premium DB961WP answers that call for increased durability, providing the Pro-Class dependability and reliability you demand, regardless of your mission. Coupling massive torque and high speed with its wide voltage range and high resolution/low deadband circuitry, the DB961WP will deliver your hobby to a new level.

Video Overview



Product Specifications

Programmable Yes
Servo Size Category Standard
Maximum Servo Speed 0.15 sec/60 deg @ 7.4V
Product Length 1.58" (40 mm)
Connector Type Universal
Product Width 0.79" (20 mm)
Maximum Servo Torque 763oz/in @ 7.4V
Deadband 1µs
Product Height 1.54" (39 mm)
Servo Type Digital
Application High Performance Aircraft, 1/10 - 1/8 Cars
Overload Protection Yes
Product Weight 3.18oz (90g)
Spline Count 25 - Tooth
Water-Resistant Yes
Motor Type Brushless
Servo Operating Voltage 4.8 - 8.4V (HV)
Bearing Dual Oversized
Bushing Or Bearing Bearing
Gear Type Metal
Wire Gauge 20 AWG
