D845WP Giant Scale Digital Monster Torque Waterproof Steel Gear Servo

Item No. HRC36845
$114.99
RC Club points earned on this item shown at checkout.
In Stock
Selected Store
The link to D845WP Giant Scale Digital Monster Torque Waterproof Steel Gear Servo has been copied

Product Details

The D845WP servo is a IP-67 rated servo capable of being truly waterproof, dust resistant, and ready for 1/5th-scale Rock Crawlers and Off-Road Trucks. As with our entire “D” line, this technologically-advanced servo is powered by our 32-bit MCU (Microcontroller Unit) and 12-bit ADC (Analog to Digital Converter) industrial science and possess Smart Sense engineering with rapid, high resolution response. The unprecedented programmability and wide-voltage capabilities deliver the most progressive, leading-edge performance for all your radio control needs. With incredibly durable steel gears, dual ball bearing and hardened steel output shaft, the high-end performing D845WP produces the mighty torque and reliability required to take bashers to the next level.
Key Features
  • Speed: @4.8V .26sec/60' / @7.5V .17sec/60'
  • Torque: @4.8V 452oz/in / @7.4V 695oz/in
  • Programmable PWM Digital Amplifier
  • 32-Bit MCU with 12-Bit ADC Circuitry
  • 4096 Resolution
  • 1M Cycle Long Life Potentiometer
  • Wide Operating Voltage (4.8 ~ 8.4 Volts DC)
  • Dual Ball Bearing Supported Output Shaft
  • 25-Tooth Output Spline
  • Coreless Metal Brush Motors
  • Nylon Reinforced Plastic Upper and Lower Case
  • Diamond Cut Aluminum Heat Sink Center Case
  • IPD 67 Rated Water Resistant and Waterproof Proof Case
icon-box
In The Box
  • (1) D845WP Giant Scale Digital Monster Torque Waterproof Steel Gear Servo
D845WP Giant Scale Digital Monster Torque Waterproof Steel Gear Servo
Quick Links
icon-pdf-download Manuals & Support

Highlights of the D-Series Servos



Product Specifications

Programmable Yes
Servo Size Category Giant Scale
Application Giant Scale Cars
Product Weight 8.0 oz (227g)
Spline Count 15 - Tooth
Water-Resistant Yes
Deadband 1µs
Input Voltage 4.8V ~ 7.4V
Product Height 2.44" (62 mm)
Servo Type Digital
Current Draw Stall 10,000 mA
Motor Type Brushed
Servo Operating Voltage 4.8 - 8.4V (HV)
Current Draw Idle 30 mA
Product Width 1.26" (32 mm)
Connector Type Universal
Maximum Servo Speed 0.26 sec/60 deg @ 4.8V, 0.17 sec/60 deg @ 7.4V
Product Length 2.6" (66 mm)
Maximum Servo Torque 452oz/in @ 4.8V, 695oz/in @ 7.4V
Bearing Dual Ball Bearing
Bushing Or Bearing Bearing
Gear Type Metal
Wire Gauge 20 AWG
