1/24 SCX24 Jeep JT Gladiator 4WD Rock Crawler Brushed RTR, Blue

Item No. AXI00005T2
Brand Logo
5 out of 5 Customer Rating

1/24 SCX24 Jeep JT Gladiator 4WD Rock Crawler Brushed RTR, Blue

Item No. AXI00005T2
$134.99
RC Club points earned on this item shown at checkout.
Color:
Select Options
7.4v 350mAh 2S LiPo Battery: SCX24 PH 2.0
AXI00005T2 DYNB0012
7.4v 350mAh 2S LiPo Battery: SCX24 PH 2.0
In Stock
$18.99
0 Item Selected Items Selected
S155 55W AC G2 Smart Charger
AXI00005T2 SPMXC2050
S155 55W AC G2 Smart Charger
In Stock
$59.99
0 Item Selected Items Selected
Adapter: IC3 Battery / JST-PH 2.0 Device
AXI00005T2 SPMXCA309
Adapter: IC3 Battery / JST-PH 2.0 Device
In Stock
$7.99
0 Item Selected Items Selected
1/24 Big Bore Scaler Shocks (4): SCX24
AXI00005T2 PRO638700
1/24 Big Bore Scaler Shocks (4): SCX24
In Stock
$39.99
Differential Cover, Brass: SCX24, AX24
AXI00005T2 AXI302001
Differential Cover, Brass: SCX24, AX24
In Stock
$19.99
Hex Hub, Brass (2): SCX24, AX24
AXI00005T2 AXI302002
Hex Hub, Brass (2): SCX24, AX24
In Stock
$11.99
Knuckles, Brass (L/R): SCX24, AX24
AXI00005T2 AXI302003
Knuckles, Brass (L/R): SCX24, AX24
In Stock
$41.99
Knuckle Weights, Brass (4): SCX24, AX24
AXI00005T2 AXI302004
Knuckle Weights, Brass (4): SCX24, AX24
In Stock
$26.99
Servo Mount, Brass: SCX24, AX24
AXI00005T2 AXI302005
Servo Mount, Brass: SCX24, AX24
In Stock
$21.99
Rear Upper Link Mount, Brass: SCX24
AXI00005T2 AXI302006
Rear Upper Link Mount, Brass: SCX24
In Stock
$13.99
0 Item Selected Items Selected
Firma 8A Sensored Brushless ESC / Motor Combo: 1/24 Rock Crawlers
AXI00005T2 SPMXSEMC18
Firma 8A Sensored Brushless ESC / Motor Combo: 1/24 Rock Crawlers
In Stock
$39.99
0 Item Selected Items Selected
Only manufacturer discounts can be applied to this product. Tower Hobbies coupon codes not applicable
In Stock
Selected Store

Product Details

The officially licensed, ready-to-run Axial® SCX24™ Jeep® JT Gladiator 4WD recreates the 2020 North American Truck of the Year in outstanding detail. Its proven chassis features a new, extended wheelbase for better handling and unstoppable performance.
Key Features
  • Factory-assembled and ready-to-run, with 2-channel radio, 88T brushed motor, servo, ESC/receiver unit and AA transmitter batteries
  • Detailed Jeep® Gladiator body and interior complete with scale driver and Tuff Stuff Overland scale accessory pack mounted to the bed rack
  • Officially licensed Nitto Trail Grappler M/T tires mounted on officially licensed KMC XD Machete wheels
  • True full-time 4-wheel drive
  • 22mm longer wheelbase for best body fit and ability to muscle over big challenges
icon-box
In The Box
  • (1) Axial® SCX24™ Jeep® Gladiator 1/24 Scale 4WD RTR
  • (1) Horizon 2.4GHz 2-Channel Radio System
  • (1) Axial AS-1 Servo
  • (1) Horizon ESC/Receiver Combo
  • (1) USB Charger
  • (1) Dynamite® 88T Brushed Electric Motor
  • (1) Dynamite 350mAh 2S LiPo 7.4V
  • (4) AA Batteries for Transmitter
  • (1) 1/24 SCX24 Jeep JT Gladiator 4WD Manual
icon-how-to
Needed to Complete
  • Nothing! Everything is included in the box!
1/24 SCX24 Jeep JT Gladiator 4WD Rock Crawler Brushed RTR, Blue

Features

  • Factory-assembled and ready-to-run, with 2-channel radio, 88T brushed motor, servo, ESC/receiver unit and AA transmitter batteries
  • Detailed Jeep® Gladiator body and interior complete with scale driver and Tuff Stuff Overland scale accessory pack mounted to the bed rack
  • Two LED lights in front bumper plus an extra LED light port on the ESC for adding optional LED lights
  • Officially licensed Nitto Trail Grappler M/T tires mounted on officially licensed KMC XD Machete wheels
  • True full-time 4-wheel drive
  • 22mm longer wheelbase for best body fit and ability to muscle over big challenges
  • Durable 3-link front/4-link rear suspension and coilover shocks for optimal handling and crawling performance
  • Worm drive gears in front and rear differentials increase ground clearance
  • Sturdy steel C-channel frame rails with bracing for added strength and proper alignment
  • Durable steel axles provide strength and durability to match tough climbs and rough trails
  • Hook-and-loop body hinge for easy, tilt-open battery access
  • 2-Year limited warranty (see product manual for details)

Exciting Scale Realism In A Crawl-anywhere Size

Now every auto enthusiast who admires the full-size 2020 North American Truck of the Year can own and drive their own officially licensed, 1/24 scale RC version — the Axial® SCX24 Jeep® JT Gladiator 4WD RTR.

No previous radio control experience is needed because it's easy to drive, fully assembled and ready-to-run. The truck is built on the proven Axial® SCX24 chassis, so even the most dedicated RC crawling fan will be proud to have it in their lineup. And serious scale modelers will be excited to find that the SCX24 Jeep® JT Gladiator not only looks great but performs well, too.

The 1/24 scale Axial® SCX24 Jeep® JT Gladiator 4WD makes any spot the perfect setting for RC adventures. If you're stuck at work, go crawling on your desk. A messy room becomes an ideal obstacle course. Test your skills on an indoor "crawl course table" or take your SCX24 Jeep® JT Gladiator outdoors, where its water-resistant electronics are safe from the elements. You can set up an exciting trail in minutes with a few holes, twigs and rocks.

Whatever course you follow, the SCX24 chassis meets every challenge with full-time 4-wheel drive, a trail-taming 3-link front/4-link rear suspension and much more. Realistic steel frame rails stand up to hard knocks. Worm gears on the axles increase ground clearance. The new, 22mm longer wheelbase increases stability while steel front and rear axles, front stub axles and steel dogbones let you crawl and climb with confidence. Power is supplied by a Dynamite® 88T motor and 2S LiPo battery. A 2-channel radio system is included for precise, dependable control.

The Axial® SCX24 Jeep® JT Gladiator performs great and looks incredibly realistic. The authentic scale body includes a driver and detailed interior and is available in your choice of two colors based on the current Jeep® Gladiator factory colors. Scale Tuff Stuff Overland accessories are mounted on the bed rack. Officially licensed Nitto Grappler tires on KMC wheels add realism plus excellent grip on- and off-road. Two LEDs in the front bumper light up the trail for night-time crawling.

The Axial® SCX24 Jeep® JT Gladiator 4WD lets anyone experience "Truck of the Year" driving adventure — with "no work, all play" ready-to-run ease!

Video Overview



Support Video Playlist



Header Image



NEW LONGER WHEELBASE
NEW LONGER WHEELBASE

The wheelbase has been lengthened by 22mm on the SCX24 Jeep® JT Gladiator for a whole new set of abilities — increasing stability and enabling the vehicle to muscle more easily over big challenges.



EXTREME BODY DETAILS
EXTREME BODY DETAILS

In addition to its officially licensed and factory-finished scale body, the SCX24 Jeep® JT Gladiator includes a detailed interior with scale driver and Tuff Stuff Overland scale accessory pack mounted to the bed rack.



STEEL C-CHANNEL CHASSIS FRAME RAILS
STEEL C-CHANNEL CHASSIS FRAME RAILS

Just like the 1/10 scale SCX10 platform, the SCX24 chassis features rugged and sturdy steel C-channel frame rails with bracing to keep everything intact and aligned.



DYNAMITE 88T BRUSHED MOTOR
DYNAMITE® 88T BRUSHED MOTOR

The Dynamite 88T brushed electric motor provides the right amount of torque for making steep climbs. It's mated to a steel motor mount to keep flex to a minimum and help protect the gears.



WORM GEARS
WORM GEARS

The front and rear differentials each house a worm screw and worm gear setup to get the power to the axles and create higher ground clearance.



FRONT AND REAR SOLID AXLE HOUSINGS
FRONT AND REAR SOLID AXLE HOUSINGS

The front and rear axles consist of a two piece, molded composite solid axle design. For optimal handling, the SCX24 suspension features a three-link front and four-link rear setup.



DURABLE STEEL AXLES
DURABLE STEEL AXLES

Steel front and rear axles, front stub axles and steel dogbones provide strength and durability needed to keep running with confidence during tough climbs and over rough trails.



SPLINED DRIVE SHAFTS
SPLINED DRIVE SHAFTS

The front and rear drive shafts are splined and sleeved to allow for maximum suspension travel while keeping the power to the wheels.



COILOVER SHOCK ABSORBERS
COILOVER SHOCK ABSORBERS

Even at this small scale, the combination of coilover shocks with simulated reservoirs and durable composite suspension links delivers the crawling performance you expect from an Axial® vehicle.



LED LIGHTS INCLUDED
LED LIGHTS INCLUDED

Two bright LED lights are included and mounted in the front bumper. An extra LED light port on the ESC allows you to add optional LED lights.



4-LINK REAR SUSPENSION
4-LINK REAR SUSPENSION

The rear suspension geometry uses a 4-link design which is optimized to reduce axle steer and torque twist.



KMC XD229 MACHETE CRAWL WHEELS & NITTO TRAIL GRAPPLER M/T TIRES
KMC XD229 MACHETE CRAWL WHEELS & NITTO TRAIL GRAPPLER M/T TIRES

The officially licensed Nitto Trail Grappler M/T tires offer a fantastic blend of off-road performance while retaining excellent composure for on-road use. The tires are mounted on officially licensed KMC XD wheels, which are legendary in the off-road world. Molded in black with a satin silver finish, the wheels feature stunning detail even at 1/24 scale!



HINGED BODY SYSTEM
HINGED BODY SYSTEM

The hinged body system provides easy access to on-board components. Its hook-and-loop hinge design lets you reach the chassis and battery quickly by simply swinging the body up.



FULL BALL BEARINGS
FULL BALL BEARINGS

Just because the SCX24 is small doesn't mean its features follow suit. There are no bushings here — the drivetrain spins freely on sealed cartridge bearings throughout the entire vehicle.



AXIAL<sup>®</sup> AS-1 SERVO
AXIAL® AS-1 SERVO

Mounted just above the front axle is the Axial® AS-1 servo, with a servo saver that allows for steering accuracy while protecting the servo gears in the event of a bind or impact.



Footer Image



Product Specifications

Approximate Assembly Time No Assembly Required!
Ball Bearings Full
Battery Included
Body Axial® Jeep® JT Gladiator
Bushing Material Plastic
Charger Included
Chassis Stamped Steel Chassis Rails
Completion Level Ready-To-Run
Connector Type PH 2.0 (High-Current Ultra Micro)
Differential Worm Gear 16T/4T
Drive Type Forward/Brake/Reverse
Drivetrain 4WD
Front Track 3.9 in
Ground Clearance 1.06 in
Make Jeep
Motor Size 030 Brushed Electric Motor
Motor Type Brushed
Pinion 10T
Power Type Electric
Product Height 4.4" (112 mm)
Product Length 9.6" (244 mm)
Product Weight 9.45 oz (268g)
Product Width 3.9" (99 mm)
Radio Included
Rear Track 3.9 in
Receiver Included
Scale 1/24
Servos Included
Shock Type Coil-over .9-1.3 in
Speed Control Included
Spur Gear 55T
Steering Type 2WS
Suspension Solid Axle, Front and Rear
Tire Tread Nitto Trail Grappler M/T
Vehicle Type Rock Crawler
Wheel Width .48 in
Wheelbase 6.1" (155 mm)
