Pre-Order
Brand Logo
5 out of 5 Customer Rating

1/10 Quirkhopper GF-02 4WD Off-Road Buggy Kit

Item No. TAM58756
1/10 Quirkhopper GF-02 4WD Off-Road Buggy Kit
1/10 Quirkhopper GF-02 4WD Off-Road Buggy Kit
Pre-Order
Brand Logo
5 out of 5 Customer Rating

1/10 Quirkhopper GF-02 4WD Off-Road Buggy Kit

Item No. TAM58756
$189.00
RC Club points earned on this item shown at checkout.
Releasing April 2026
Selected Store
The link to 1/10 Quirkhopper GF-02 4WD Off-Road Buggy Kit has been copied

Product Details

This R/C kit depicts the Tamiya Quirkhopper, an original body design mated on the easy to build GF-02 chassis.
Key Features
  • 1/10 Scale R/C Assembly Kit
  • Customizable Polycarbonate Body
  • Large-Diameter Tires
  • Electronics Included
icon-box
In The Box
  • (1) 1/10 Quirkhopper GF-02 4WD Off-Road Buggy Kit
  • (1) 540-Size Brushed Electric Motor
  • (1) HobbyWing THW 1060 Brushed ESC
  • (1) 1/10 Quirkhopper GF-02 Manual
icon-how-to
Needed to Complete
  • (1) 2+ Channel Radio System
  • (1) Standard-Size Steering Servo
  • (1) 7.2V - 7.4V Battery
  • (1) Battery Charger
1/10 Quirkhopper GF-02 4WD Off-Road Buggy Kit

About the GF-02 Chassis

The gear-driven 4WD GF-02 chassis features its motor in a low, central position in the lightweight, durable monocoque frame, and transmits power to front and rear via gears. The long wheelbase and wide tread setup ensure stable off-road performance. The slim frame features ladder/pipe motifs and features integrated sealed gearboxes which help keep stones out. Front and rear gear differentials allow smooth cornering, while separately sold pinion gears offer a choice from three types of gear ratios, and a motor guard enhances reliability off-road. The 4-wheel double wishbone suspension employs four friction dampers, and the steering servo is positioned on the left with identical-length tie-rods.

Key Features

  • 1/10 scale R/C model assembly kit. Length: 400mm, width: 280mm, height: 175mm. Wheelbase 267mm.
  • Paint the 0.7mm thick lightweight, rigid polycarbonate body as you wish.
  • The front of the body features two headlights, and rear has wing integrated with large air intakes.
  • 123mm large-diameter tires.
  • Includes dedicated stickers.
  • Includes 540-Type motor and ESC.
  • Required to complete: 2-channel radio, steering servo, 7.2-7.4volt battery with compatible charger and Tamiya PS paints.

Product Specifications

Ball Bearings Plastic Bushings
Battery Sold Separately
Body Clear Polycarbonate
Bushing Material Plastic
Charger Sold Separately
Chassis ABS Plastic
Completion Level Kit
Differential Gear Differentials
Drive Type Forward/Brake/Reverse
Drivetrain 4WD
Gear Ratio Fixed
Manufacturer # 58756
Motor Size 540
Motor Type Brushed
Power Type Electric
Product Height 6.89" (175 mm)
Product Length 15.75" (400 mm)
Product Width 11.02" (280 mm)
Radio Sold Separately
Receiver Sold Separately
Scale 1/10
Servos Sold Separately
Shock Type Friction Damper
Speed Control Included
Suspension Fully Independent Double Wishbone
Vehicle Type Buggy
Wheelbase 10.51" (267 mm)
